Price:
$ 36.55

Free Shipping

For just $ 36.55 , buy X96 Link S905w Android TV Set Top Box 2G + 16G High-end Smart Router – US Plug from the wholesale webshop online.

Specifications

Bluetooth No
Certificate CE
CPU Amlogic S905W Quad-core 64-bit
CPU Type Quad Core
Ethernet 100M
GPU Penta-core Mali-450MP
IPTV No
OS Android
Plug US Plug
RAM 2GB
Retail Packaging Paper Box
ROM 16GB
User Manual (Language) English
Video Output HDMI 2.0
Wireless Yes
Gross Weight 0.672kg
Volume Weight 0.557kg
Length 19.500cm
Width 15.000cm
Height 8.500cm
Weight 0.600kg
With Retail Packaging Yes

Product Description

X96 Link S905w Android TV Set Top Box 2G + 16G High-end Smart Router – US Plug
  • System: Android 7.1 .2 supports a large number of application downloads

  • Secure Network: X96 Link automatically shields other network devices, and block webpages containing Trojans

  • No Delay in Network: Mimo technology can simultaneously transfer data to multiple users.One-to-one wifi service, fast speed, games and movies more fun

  • Multi-scene Application: X96 Link can be used in different places, such as home, shopping mall, restaurant, conference room, etc. It provides fast and stable speed, and wide wireless coverage

  • Equipped with Dual Chips: Equipped with Amlogic S905W quad core ARM cortex A53 and SIFLOWER SF 16A18 chips, X96 Link will provide you a better enjoyment both from router and smart tv box

Specification:

OTT Parameters
CPU Amlogic S905W Quad Core ARM Cortex A53 @2GHz
GPU Penta-core Mali-450MP GPU @ 750MHz
RAM DDR3: 2GB
Memory eMMC: 16GB
WiFi NOT/Connect Router
Moudle Plastic : Black Color
HDMI 1*HDMI/4K*2K UHD Output, HDMI 2.0A
AV Port 1*AV OUT/480i/576i standard definition output
USB Port 4*USB /USB Host Port
IR  Reciver 1*IR Reciver/Remote Reciver Connect
RJ45 GbE Interface input/Share with Routers
TF CARD 1*TF CARD/ Support 4GB/8GB/16GB/32GB/64GB
Power DC 12V/2A; LED indicator (Working: Blue; Standby: Red)
Router Parameters
CPU SIFLOWER SF16A18
RAM 64MB/32*16
Indicator 4*LED/WIFI WAN LAN1 LAN2
2.4G WIFI Speed 150M
5G WIFI Speed 433M
WPS Function Support
WIFI Standard 802.11 ac/a/n; 802.11 b/g/n, Support MU-MIMO
WIFI Band 2.4GHZ; 5GHZ/Dual band
WIFI Agreement 802.11 ac/a/n; 802.11 b/g/n
Special Functions Support IPv6/IPv4
WAN Port 1*GbE Prot
LAN Port 2*100 M Ethernet  Prot
 OTT Software
OS Android 7.1.2
Video * AMLogic video Engine(AVE)with dedicated hardware decoders and encoders
* Supports multiple "secured"video decoding sessions and simultaneous decoding and encoding
* Video/Picture Decoding
   -VP9 Profile-2 up to 4K*2K
   -H.265 HEVC MP-10@L5.1 up to 4K*2K@
   -H.264 AVC HP@L5.1 up to 4K*2K
   -H.264 MVC up to 1080P@60fps
   -MPEG-4 ASP@L5 up to 1080P@60fps(ISO-14496)
   -WMV/VC-1 SP/MP/AP up to 1080P@60fps
   -AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
   -MPEG2 MP/HL up to 1080P@60fps
   -MPEG1 MP/HL up to 1080P@60fps
   -RealVideo 8/9/10 up to 1080P@60fps
* Low latency 1080P H.264 60fps encoder
* HDR10 and HLG HDR Video Processing
* Supports *.mkv,*.mpg,*.wmv,*.mpeg,*.dat,*.avi,*.mov,*.iso,*.mp4,*.rm and    *.jpg file formats
* Video/Picture Encoding
   -Independent JPEG and H.264 encoder with configurable performance/bit-rate
   -JPEG image encoding
   -H.264 video encoding up to 1080P@60fps with low latency
Audio Low power MediaCPU with DSP audio processing
Supports MP3,AAC,WMA,RM,FLAC,Ogg and programmable with 7.1/5.1 down-mixing
Built-in stereo audio DAC
Built-in SPDIF/IEC958 and PCM serial digital audio input/output
Supports concurrent dual audio stereo channel output with combination of    analog+PCMo or I2S+PCM
Image HD JPEG, BMP, GIF, PNG, TIF
Language English/French/German/Spanish/Italian, etc.    multilateral languages
Appliactions
Online Browse all video websites, support Netflix, Hulu, Flixster,  Youtube, etc.
Apps Apps download freely form android market, amazon app store etc.
Medium Local Media playback, support HDD, U Disck, TF Card.
Talk online Support SKYPE video call, MSN, facebook, twitter, QQ, etc.
Others Support Email, office suit, etc.
Support DLNA function
Support 2.4G wireless mouse/keyboard
Router Software
User    Management Support

WIFI Pattern

Low/Middle/High
Language Chinese/English
Advanced Function Administrator network/Visitor network

Package included:

  • 1 x HDMI Cable
  • 1 x IR Remote
  • 1 x Power Adapter
  • 1 x English User Manual
