SC8108 Multifunctional Portable LCD Digital Display Network Tester LAN Phone Cable Meter – Black

This is a professional network cable tester with automatic scanning method, fast test, easy to carry, more suitable for on-site operation.

• The connectivity test can be carried out, single cable

• Can detect 5E, 6E network cable and telephone line wiring faults, open circuit, short circuit, including: cross connection, reverse connection and series winding

• Localization and connection/connection errors (but not for shielded cables, STP cables cannot work)

• Measure the cable length and the specific location of the open circuit and short circuit

• With cable length dynamic calibration function, the length measurement accuracy is up to 97%

• Easy to use, large screen display makes test results clear at a glance

• Easy to carry, with automatic delay shutdown function

• No length measurement, and a matching pair can be inserted on the distal recognizer

• Cable position, 8 distal passive testing sockets (identification number ID1-ID8)

• With distal identification appliance audio prompt function and self checking function, self checking function can automatically compensate for changes in battery power and the effects of changes in ambient temperature

• Designed of MCU software watchdog, which makes operation more reliable

Specification:

• Model: SC8108

• Material: plastic

• Testing cable: RJ45 RJ11

• Battery: 4 * AAA battery (not included)

• Power consumption: 25mA
